520HPA Hydraulic Guillotine w/ Air Table

Fully hydraulic system, foot pedal for pre-clamping, adjustable clamp pressure, 99 programs with 10 steps each, safety beam for safe operation, big color touch screen in mm/inch, air table for effortless moving of paper stack, LED working light for better working environment

VIDEO PLAY
CATALOG
Χ

Specifications

*Photo and video show 520HP. 520HPA is equipped with air table. Please refer to "Main Features" to check out the air table.


Fast cutting speed, suitable for printing houses and copy centers.



Specifications:


Cutting Width520mm / 20.47"
Cutting Height80mm / 3.15"
Narrow Cut15mm / 0.59"
Cutting Depth580mm / 22.84"
Dimensions (H x W x D)1396 x 946 x 1300mm
Power Supply230V 50/60Hz 1PH 20A
Weight430 kg



Main features:




With air table and working light

   Adjustable clamp pressure



Other features and functions:


- Fully hydraulic system

- Adjustable clamp pressure

- Foot pedal for pre-clamping and optical cutting line indicator

- 99 programs with 10 steps each

- Big color touch screen in mm/inch

- LED working light

- Air Table

- Safety beam for safe operation

- Safety two-handed operation

- Safety blade change device

- Main power switch and safety key lock

- High quality blade

- Blade fine-depth can be system controlled

- Electronic hand wheel for backgauge position with variable speed

- Power supply: 230V 50/60Hz 1PH 20A

- Option: Side tables (W : 305mm)



520HPA without side tables
