CP376B High Pile Feed
Digital system, automatic suction feeding, 7" color touch screen, creasing depth and angle adjustable, easy knife change, stepless regulation for suction / blow volume, manual feed mode, optional: cross perforating, cross slitting (kiss cutting), cross creasing, cross partial perforating, knife folder, small feeder, central feeder
VIDEO PLAY
CATALOG
Χ
Specifications
| Paper Size | Max.: 370 (W)*3,000 (L) mm Min.: 210 (W)*140 (L) mm (Standard) Optional Feeder Required: 140 (W)*140 (L) mm 90 (W)*90 (L) mm |
| Control Panel | 7" Color Touch Screen |
| Paper Feed Type | Top Suction Feeding |
| Standard | Creasing Bar, Perforating Bar |
| Optional | Cross Rotary Knives: Creasing, Perforating, Slitting (Kiss Cutting), Partial Perforating Others: Knife Folder, Small Feeder, Central Feeder |
| Speed | 10,000 sheets / hr (A4 / 1 Creasing) |
| Paper Thickness | 70 gsm - 450 gsm |
| Memory | 32 Programs |
| Feeding Tray Capacity | 600mm |
| Creasing Accuracy | ±0.2mm |
| Creasing per Sheet | Max. 32 Lines |
